PIONEER - DJM2000 Nexus

FUTUROLOGY FULFILLED.The DJM-2000NXS combines advanced performance features and an intuitive layout to empower unbridled creativity in the booth. A newly designed Peak Limiter eliminates distortion and clipping even at club volumes, all four channels are equipped with a Peak Level Meter so you can check your input levels at a glance.The perfect match for our flagship CDJ-2000NXS digital decks, the DJM-2000NXS features ProDJ Link for a smooth connection, while the club-standard design – with chrome-plated knobs and white LED buttons – makes sure they can be placed side-by-side in total harmony.ADVANCED CONNECTIVITY??With Pro DJ Link you can connect multiple players, turntables or laptops via LAN connection and share a single source. Combine this with rekordbox to access pre-prepared loops and cues, sync the beat with the master deck, and access a host of advanced pro-DJ features.??BEAT SLICE??Sample and slice tracks on-the-fly for spontaneous creativity.??FREQUENCY REMIX??Choose which frequencies are in the mix with a 7-band touch cross fader.??SIDE CHAIN REMIX??Borrowed from the groundbreaking RMX-1000 remix station, Side Chain Remix delivers louder side chain oscillators and multiple effect chaining.??USB AUDIO INTERFACE??Connect via USB to play tracks from your PC/Mac without an external soundcard. Assign a different input to each channel or output audio from the master channel to your computer for easy recording.??QUANTIZED BEAT FX??Quantize snaps Beat FX, cues and loops to the rekordbox beat grid for precision performances.??Main Features

MIDI Control

Full assignable MIDI controls
MIDI Clock Output

ProDJ Link : Yes
Auto Standby : Yes
rekordbox Link : Yes

Specifications

Frequency Range : 20 – 20,000 Hz
Sampling Rate : 96 kHz
A/D Converter : 24 bit
D/A Converter : 32 bit
S/N Ratio Line : 107 dB
S/N Ratio Phono : 93 dB
S/N Ratio Mic : 85 dB
Crosstalk Line : 82 dB
Distortion : < 0.004 % Headroom : 19 dB Power Consumption : 40 W Master Master Balance : Yes Stereo/Mono Switch : Yes Level Meter Size : 15 segment Master Out Attenuator : Yes Channels EQ/ISO : 3 band EQ/ISO Range : Switchable isolator: -∞ ~ +6 dB / Standard: -26 dB ~ +6 dB Level Meter Type : Individual Level Meter Size : 15 segment Peak Limiter : Yes Performance Control Channels : 4 Sound Color FX Crush HP Filter Jet LP Filter Noise Zip Beat FX Delay Echo Filter Gate Multi Tap Delay Phaser Reverb Reverse Roll Roll Slip Roll Trans FX Frequency : Yes rekordbox Quantize : Yes Performance Modes Beat Slice Frequency Remix MIDI Side Chain Remix Effect/Sampler 3-Band Isolator : Yes Auto BPM Counter : Yes Beat Sampler : Yes Direct Beat Select : Yes Effect Level & Depth Volume : Yes Effect Mix : Yes Inloop Sampler : Yes Live Sampler : Yes MIDI Global Clock : Yes Roll Sampler (Fwd) : Yes Roll Sampler (Reverse) : Yes Sidechain Remix Effects : Yes Sound Processor : 32 Touch Panel : Yes Crossfader CURVE Assignable : Yes Field Replaceable : Yes Fader Curve : 3 Mic Mic Connection : Neutrik Combo Mic EQ:  2 band Mic EQ Range : -12 dB ~ +12 dB Talkover : 3 Position Switch Talkover Attenuator : Yes MIDI Info Assignable Controls : Touchscreen & Interface MIDI Out (DIN) : 1 (5P DIN) MIDI On/Off : Yes MIDI Start/Stop : Yes MIDI Clock : Yes Sound card Connection : USB Stereo Inputs : 4 Stereo Outputs : 1 Sample Rate : 24 bit Frequency : 96 kHz Terminals Inputs 1 MIC (XLR/Jack Combo) 2 PHONO (RCA) 4 S/PDIF Digital (RCA) 6 CD/LINE (RCA) Send/Return 2 SEND (1/4 inch Jack) 2 RETURN (1/4 inch Jack) LAN : 6 USB : 1 USB B port Outputs 1 BOOTH (1/4 inch Jack) 1 HEADPHONE MONITOR (1/4 inch Jack) 1 REC (RCA) 1 S/PDIF Digital (RCA) 2 CONTROL (Mini-jack) 2 MASTER (XLR, RCA)
