L-ACOUSTICS - X15 HiQ

In the L-Acoustics coaxial X series, the X15 HiQ is the reference active stage monitor. It operates from 55 Hz to 20 kHz.

The X15 HiQ features a 3’’ diaphragm compression driver coaxially-loaded by a 15’’ low frequency transducer in a bass-reflex enclosure with laminar vents.

The coaxial transducer arrangement and its ellipsoid waveguide produces a 40° x 60° directivity pattern with a smooth tonal response free of secondary lobes over the entire frequency range. As a result, X15 HiQ boasts an exceptional immunity to feedback in stage monitoring situations.

The X15 HiQ provides a stage monitoring angle setting of 35° with regard to vertical or 55° thanks to its built-in risers. With a cabinet combining the properties of birch and beech plywood, X15 HiQ low weight and elegance makes for an easy integration into the set. Ergonomic handles for a solid grip and efficient handling. For special narrow fill applications, the X15 HiQ can be pole-mounted using the integrated socket or flown and tilted in various orientations using its rigging accessories.

The amplified controllers ensure the advanced crossover functions, time alignment, linearization and L-Drive protection of the transducers

Specifications

• Description : active 2-way coaxial enclosure, amplified by LA4X / LA8
• Usable bandwidth (-10 dB) : 55 Hz – 20 kHz ([X15])
• Maximum SPL : 136 dB
• Nominal directivity
  • vertical: 60°
  • horizontal: 40°
• Monitoring angle
  • 35° without raisers
  • 55° with raisers
• Transducers
  • LF: 1 × 15″ weather-resistant, bass-reflex, laminar vents
  • HF: 1 × 3″ compression driver neodymium, weather-resistant, ellipsoidal waveguide
• Nominal impedance
  • LF: 8 Ω
  • HF: 8 Ω
• Connectors
  • IN: speakON
  • LINK: speakON
• Rigging and handling
  • 2 × handles
  • DIN580-compatible M8 threaded insert
  • 4 × M10 threaded inserts
  • 2 × 35 mm pole sockets
• Cabinet : first grade Baltic beech and birch plywood
• Finish :
  • dark grey brown PANTONE 426C
  • pure white RAL 9010
  • custom RAL code on special order
• IP : IP43
